CV1200 Specifications: Digital Duplicator

Considerable experience in varied markets provides RISO with
insights on customer requirements across the world.

CV series from RISO is the result of these valuable insights and RISO's in-house R&D.
It provides all the benefits that our customers desire including cost- and time-saving combined with ease of operation, superior print quality and a user-friendly design.
The CV series delivers Customer Value, like no other equipment in its class.

The CV series increases printing efficiency

High-speed printing of 100 ppm

The CV1200 provides high-speed printing of up to 100 ppm which means 500 pages in just 5 minutes.

Adequate paper capacity

The paper trays have a capacity of approx. 1000 sheets for feeding and approx. 800 sheets for receiving, which ensures uninterrupted printing over a longer period.

Note: The paper capacity depends on paper type.

Designed with the customer's needs in mind

Easy-to-operate LED panel

LED panel is clearer to view and easier to operate.

Convenient PC connectivity via USB

Inbuilt USB PC interface enables easy connection to a PC.

Achieved through RISO's cutting-edge technologies

Quality output from various types of originals

Four image-processing modes: Line, Photo, Duo, and Pencil are selectable.

Auto base control

Automatically compensates for newspaper originals or originals made on recycled paper, removing the background greyness so your output always has a clear, white background.

Versatile paper handling capability

The CV series accepts a wide range of paper types including recycled paper.

Three enlargement and four reduction settings

Easy operation with preset buttons. Just press your required size, it's fail-proof.

User-oriented design for extended use

RISO i Quality System

Recognizes master and ink information by two-way communication with attached RF tag and adjusts the performance automatically. This contributes to quality stability and improvement. It also supports inventory control of consumables.

RISO iQualitySystem

Paper saving

- 2-Up printing
Reduces paper by printing two originals onto one sheet of paper.

- Direct printing
No need to prepare an original before printout.Direct data processing prevents paper wastage.

High-quality RISO consumables

RISO is the only company to develop and manufacture both the machine and consumables in-house, thus assuring consistent and high-quality output.

RISO MASTER CV B4

RISO INK CV BLACK

Specifications	CV1200
Master Making / Printing Methods	High-speed digital master-making/Fully automatic printing
Original type	Sheet
Original Size (min./max.)	90 mm x 140 mm to 310 mm x 435 mm (3 17/32 inches x 5 1/2 inches to 12 7/32 inches x 17 1/8 inches)
Original Paper Weight	50 gsm to 107 gsm (13-lb bond to 29-lb bond)
Original Paper Capacity	1 Sheet
Scanning Area (max.)	297 mm x 435 mm (11 11/16 inches x 17 1/8 inches)
Printing Paper Size (min./max.)	100 mm x 148 mm to 297 mm x 420 mm (3 15/16 inches x 5 13/16 inches to 11 11/16 inches x 16 17/32 inches)
Paper Supply Capacity	Approx. 1000 sheets, 64 gsm to 80 gsm (17-lb bond to 21-lb bond)/Maximum stacking height: 110 mm (4 11/32 inches)
Paper Receiving Capacity	Approx. 800 sheets, 64 gsm to 80 gsm (17-lb bond to 21-lb bond)/Maximum stacking height: 90 mm (3 17/32 inches)
Printing Paper Weight	35 gsm to 128 gsm (9-lb bond to 34-lb bond)
Image Processing Mode	Line, Photo, Duo, Pencil
Resolution (Scanning and Printing)	300dpi x 300dpi
Master-making Time	Approx. 39 seconds or less (for B4 originals/short edge feed/100% reproduction ratio)
Printing Area (max.)	In units of mm: 251 mm x 357 mm (9 7/8 inches x 14 1/16 inches) In units of inches: 210 mm x 349 mm (8 9/32 inches x 13 3/4 inches)
Print Reproduction Ratio	In units of mm: 100% reproduction ratio, Enlargement (141%, 122%, 116%), Reduction (94%, 87%, 82%, 71%) In units of inches: 100% reproduction ratio, Enlargement (154%, 129%, 121%), Reduction (94%, 78%, 65%, 61%)
Print Speed	3 levels: 60, 80, and 100ppm
Print Position Adjustment	Horizontal:±10 mm Vertical:±10 mm^*1, (Horizontal: ±13/32 inches, Vertical: ±13/32 inches)
Ink Supply	Full automatic (800 ml/cartridge)
Master Supply/Disposal	Full automatic (B4: approx. 200 sheets per roll)/Disposal capacity: approx. 30 sheets
User Interface	LED panel
Computer Connection	USB PC Interface
Optional Accessories	Not Available
Operating Noise	Max. 69dB(A) (when printing 100 sheets per minute in the operator position)
Power Source	AC100-120V/220-240V, 50-60 Hz <2.0A/1.0A>
Power Consumption	Max. 160W, Ready: 15W or lower, Sleep: 10W or lower, Power-OFF: 0.5W or lower
Functions	Original Scanning Mode, Scanning Level, Enlargement/Reduction, 2-Up, Speed, Print Position, Program, Idling, Confidential, Meter Display, Proof, Direct Printing, Auto Sleep Setting, Auto Power-OFF Setting, RISO iQuality System
Dimensions (W×D×H)	In Use	1280 mm x 655 mm x 515 mm (50 13/32 inches x 25 25/32 inches x 20 9/32 inches)
Dimensions (W×D×H)	In Storage	665 mm x 655 mm x 505 mm (26 3/16 inches x 25 25/32 inches x 19 7/8 inches)
Required Space (W×D×H)	1280 mm x 1255 mm x 845 mm (50 13/32 inches x 49 13/32 inches x 33 9/32 inches)
Weight	Approx. 64 kg (141lb)^*2

*1 If the width of the paper surpasses 277 mm (10 29/32 inches), the vertical position adjustment width narrows depending on the width of the paper.
*2 The weight does not include the ink and master roll.
Notes: Specifications are subject to change without notice.

RISO logo is either a registered trademark or a trademark of RISO KAGAKU CORPORATION.
Other corporate names and/or trademarks are either registered trademarks or trademarks of each company, respectively.
Copyright ©2015 RISO KAGAKU CORPORATION. All rights reserved.
The color of the actual product may vary from the color shown in the content.
